Universal V band Flange Kits

Our v band flanges are perfect for joining exhaust systems & waste-gate pipes. No gaskets are required when bolting these together, they seal by the tension of the v band clamp pulling the flanges together when tightening.

Exhaust v band flanges can be used instead of exhaust flanges that require gaskets. These can fail from excess heat.

Learn vital information regarding V-band flanges here:

What is a V-band flange?

6 must knows to prevent distortion!!

• Made from 304 Stainless Steel

• Stainless Steel V band flanges have a male and female which locates into each other for alignment when clamping together

• Steel locking nut that will not melt from heat like a nyloc nut

V BAND FLANGE KIT INCLUDES:

• X2 304 Stainless Steel Weld Flanges
• x1 V band Clamp - (These are a imperial thread see below for sizes)
• x1 Locking Nut
• x1 Standard Nut

V band Clamp Thread Sizes:

1.5 inch v band flange = 1/4 unf

1.75 inch v band flange = 1/4 unf

2 inch v band flange = 1/4 unf

2.25 inch v band flange = 1/4 unf

2.5 inch v band flange = 1/4 unf

3 inch v band flange = 3/8 unf

3.5 inch v band flange = 3/8 unf

4 inch v band flange = 3/8 unf
