Evo 4-9 Factory Position - Large Runner - Turbo Manifold

After years of development of our merge collector from extensive dyno time and feedback from the top tuners in the country, we have found the perfect balance of boost control and flow. With minimal back pressure where the manifold meets the turbo, you can be sure that you're getting the best flow possible from your turbo manifold. FLOW = POWER.

For information on material types please follow the link: FAQ

Learn vital knowledge for the successful installation of your SINCO Turbo Manifold and what components will help with the long term reliability of your turbo setup!!  Click Here

Not sure on your turbo flange?? Click Here

NOTE = Evo 7, 8 & 9 top radiator hose sits more central on the top tank, this will need to be hard piped to prevent the hose from melting.(see pictures)  Evo 4, 5 & 6 radiator will have clearance.

NOTE = This position does not allow room to run a external wastegate - We do have a small runner option that does Small Runner

• Fitment Evo 4-9 with factory td05 twin scroll turbo
• Features dual 2 into 1 merge collectors
• 12mm CNC machined exhaust manifold flange
• 16mm CNC machined turbo flange
• Runner size = 41mm inside diameter

5 year no crack warranty

10 year no crack warranty if fitted by us in store

Manifold Manufacture Times

Our manifolds are made to order, manufacturing times vary depending on the time of year & our current work load.

Please email or message us if you want to know exact time frames
